• 7500W Industrial Intelligent Cold Welding Machine IP21S Protection
  • 7500W Industrial Intelligent Cold Welding Machine IP21S Protection
7500W Industrial Intelligent Cold Welding Machine IP21S Protection

7500W Industrial Intelligent Cold Welding Machine IP21S Protection

Product Details:

Place of Origin: Chongqing
Brand Name: GENWELD
Certification: CE
Model Number: LW-J750

Payment & Shipping Terms:

Minimum Order Quantity: 2 sets
Packaging Details: Packing with foam & carton, Packing size:600*400*620mm, One set/ carton
Delivery Time: 15 work days
Payment Terms: T/T
Supply Ability: 100 Sets Per Month
Get Best Price Contact Now

Detail Information

Appearance Size: 500*300*520mm Net Weight: 35kg
Input Power: 3-phase/380V/50-60Hz Max Instantaneous Output Power: >150kW
Wire Code: 0.2-5.0mm Power Consumption: 10-7500W
Protection Level: IP21S
High Light:

Industrial Intelligent Cold Welding Machine

,

7500W Cold Welding Machine

,

Intelligent Cold Welding Machine IP21S

Product Description


Working principle of LW-J750 Industrial Cold Welding Machine

Using capacitor energy storage, the electrical energy stored in the capacitor is instantly released between the tungsten electrode and the workpiece in the form of a pulsed arc. The instantaneous and precise concentrated current generated by the high-frequency arc discharge makes the temperature after welding less than the workpiece emission Temperature, so as to achieve the cold welding effect.


The difference between it and a traditional cold welding machine?

Intelligent automation, 20 sets of parameter storage function, welding height tracking system, inner hole pile welding do not need manual, high power and high efficiency, fatigue resistance.


LW-J750 Industrial Intelligent Cold Welding Machine Application:

1. Automatic sheet metal welding: automatic arc welding, straight seam welding, welding of special-shaped parts.
    Welding materials:Stainless steel, galvanized, cold rolled, iron, steel, aluminum, copper, titanium, etc.

2. Automatic cold welding & cladding: repair of outer diameter of shafts, surfacing welding of inner hole of bearing seat, roller cladding welding.
    Welding materials:High-chrome cast iron, cast iron, cast steel, stainless steel castings, alloy steel, mold steel, 45 # steel, etc.

3. Overlay welding wear-resistant layer: large area repair welding; welding of structural parts with pressure / flaw detection / sealing requirements.


LW-J750 can be used with wire feeders, robotic arms, and automated tooling


LW-J750 Industrial Intelligent Cold Welding Machine Parameters:


Equipment modelLW-J 750Product size500×300×520mm
Product weight35KGInput powerThree-phase, 380V-50/60HZ
Power consumption10-7500WInstsient max. output powerMore than 150KW
Wire code0.2-5.0mmOutput current range10-310A
Pulse speedAdjustableMode selectionSingle-point / continuous / arc welding
Aron gas delay time9SWelding heightAny
Protection levelIP21SCooling modeThe fan enforces air cooling



Main Components & Origin of LW-J750 Industrial Intelligent Cold Welding Machine:


NameBrandOrigin
Mos tubeIXYSGermany
Refer tubeSTItaly
The rectifier bridgeONAmerica
The rectifier diodeONAmerica
Module (Custom)ONAmerica
Magnetic coreTDKJapan
Capacitive (custom)Black King KongJapan
Panel Capaciance (custom-made)Red gemJapan
Power filterMooreGermany
resistorKOAJapan
The inductorSiemensGermany
