• Civil 170A 26.8V Portable IGBT Inverter Welder
Civil 170A 26.8V Portable IGBT Inverter Welder

Civil 170A 26.8V Portable IGBT Inverter Welder

Product Details:

Place of Origin: CHONGQING
Brand Name: GENWELD
Certification: CE
Model Number: LWG-190

Payment & Shipping Terms:

Minimum Order Quantity: 50 SETS
Price: USD 45 Per Set
Packaging Details: 320*150*240mm
Delivery Time: 15 work days
Payment Terms: L/C, T/T
Supply Ability: 10000sets per month
Get Best Price Contact Now

Detail Information

Welding Process: MMA Current Range: 25-170A
Electrode Diameter: 2.5mm, 3.2mm,4.0mm Dimension: 320*150*240mm
Weight: 4.1kg Protection Class: IP23
Welding Cable(m): 1.8M Ground Cable(m): 1.2M
High Light:

170A Portable Inverter Welder

,

26.8V Portable Inverter Welder

,

4.0mm Electrode Portable Inverter Welder

Product Description

GENWELD MMA190 170A Portable Inverter ARC Welder





Features:



• The front panel is equipped with overheat-protection and over-current protection indicators. The current display is used to show the current data accurately. The acceptable input voltage range 130 - 260V.



• Three-layer PCB structure ensures the performance of the welding machine. Especially, the power supply board is more safe and stable.



• Hi-speed running fan with more optimized heat sink channel design, which makes the heat dissipation effect is 30% higher than the same type of inverter welding machine.



• Full bridge Inverter IGBT dual modules, large output voltage.



• Large capacitors are more flexible and support to connect with generator use.



• The whole series of products with hot arc starting, arc force, and anti-sticking functions. Easy to start the arc, low-pressure drop, comfortable operation.



• New dust-proof design, nice appearance, more cost-effective, more portable, and lighter.



Application field



• It’s widely used for many kinds of metal welding, like carbon steel, stainless, iron and etc.





Specification sheet



Model MMA-190
Input voltage (V) 230V
Rated input power(KW) 6.5
Current range(A) 25-170(A)
Rated input current(A) 33
Efficiency % 85
Duty Cycle@40℃ 60% 100%
Insulation Class F F
NO load Voltage(V) 65
Max. output current(A) 170 132
Max.output Voltage(V) 26.8 25.3
Max. output power(W) 4556 3339.6
Rated output current(A) 170 132
Rated output Voltage(V) 26.8 25.3
Electrode(mm) 2.5,3.2,4.0
Protection Class IP23
Dimension(mm) 285*120*210
Net weight (kg) 3.7
Packing Dimension(mm) 320*150*240
Gross weight(kg) 6
Welding cable(m) 1.8
Power cable+Plug(m) 1.5
Ground cable(m) 1.2
