Oil / Gas / Water Pipeline 200A MMA TIG Engine Driven Arc Welder LWG210ST
Product Details:
| Place of Origin: | China |
| Brand Name: | Lianwai |
| Certification: | CE |
| Model Number: | LWG210ST |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 SETS |
|---|---|
| Packaging Details: | Carton |
| Delivery Time: | 20 work days |
| Supply Ability: | 1000 SETS |
|
Detail Information |
|||
| Welding Process: | MMA, TIG | Welding Current: | 40-200A |
|---|---|---|---|
| Duty Cycle: | 60%/190A/27.6V | Auxiliary Power Output: | DC 1.5kW/220V |
| Net Weight: | 65kg | Dimension: | 600*500*550mm |
| Fuel: | Gasoline | Protection/Insulation Class: | IP23 |
| High Light: | 200A Engine Driven Arc Welder,MMA TIG Engine Driven Arc Welder,70V Pipeline Engine Driven Arc Welder |
||
Product Description
LWG210ST 200A MMA / TIG Welding Generator
Introduction
LWG210ST is an industrial portable welding generator, which can output 230A welding current and 220V/50Hz single-phase 3KVA auxiliary AC power. Due to its small size, light weight, convenient movement and self-generation, it is ideal for welding in places without power supply and field construction operations.
Characteristics
1. IF power generation technology,
2. Welding current are steplessly adjustable.
3. Suitable for various brands of electrodes.
4. Beside MMA welding, it also has TIG function (scratch arc ignition type).
5. Auxiliary output: Single-phase, AC 3kW/220V/50Hz.
Application
1. Oil/gas/water pipeline welding,
2. Maintenance and repair of highway guardrails and power facilities,
3. Repair of fences and agricultural equipment in pastures and farms,
4. Supply power to small electric tools in the field without power supply: angle grinder, sander, electric drill, water pump, lighting equipment, etc.
5. Welding of stainless steel and carbon steel materials
6. Emergency power supply.
| Main specification sheet | |||
| Product Model | LWG210ST | ||
| Welding | No-load voltage | 65-70V | |
| Current range | 65A-210A | ||
| Duty cycle | MMA:60%/200A/28V TIG:60%/200A/18V |
||
| Electrode diameter | ￠2.5-￠4.0mm | ||
| Generating | Rated output power:AC single-phase/220V 3Kw | ||
| Engine | Brand | SC | B&S |
| Manufacturing country | China | USA | |
| Engine power | 15Hp | 13.5Hp | |
| Engine | Max rpm | 3600 | |
| Starting | Recoil/E-start | ||
| Lubricant alarm system | Yes | ||
| Emission(cc) | 460 | 420 | |
| Fuel capacity(L) | 15 | ||
| Lubricant capacity(L) | 1.1 | ||
| Fuel consumption(g/k.h) | 460 | 374 | |
| Overall unit | Insulation Class | H level 180℃ | |
| Net weight(kg) | 70Kg | ||
| Overall Dimensions(L×W×H) | 710*560*650mm | ||
