600A Tri-phase 400V Pipeline Welding Machine with Multi-process Welding and Dual Welding Generator
|
600A Tri-phase 400V Pipeline Welding Machine with Multi-process Welding and Dual Welding Generator
| Brand Name: | Lianwai |
| Model Number: | H600 |
| MOQ: | 2 sets |
| Delivery Time: | 45 days after received prepayment |
| Payment Terms: | T/T,,L/C |
Detail Information
Place of Origin:
Chongqing,China
Certification:
CE
Name:
600A Diesel Welding Generator
Rated Power Output:
AC400V / 25Kw / Tri-phase, AC230V / 6.9Kw / Single Phase
Engine Brand & Type:
Kubota, Yuchai, Weichai
Application:
Maintenance And Repair, Construction, Pipeline
Welding Process:
MMA/TIG/FCAW/Gouging/Cellulose
Duty Cycle:
100% / 400A / 26V
Packaging Details:
Wooden case, 1700*900*1200mm, 14 sets/20GP
Supply Ability:
100 sets per month
Highlight:
600A Dual Fuel Welder Generator
,Tri Phase Dual Fuel Welder Generator
,Pipeline Dual Fuel Welder Generator
Product Description
WD600 600A Pipeline Welding Machine
Professional dual fuel welder generator with tri-phase 400V 20kW output capability. Supports multiple welding processes including Stick, TIG, FCAW, Gouging, and Cellulose welding.
Key Features
- Simultaneous 50/60Hz single/tri-phase power output during welding operations
- Multiple premium diesel engine options with strong power, stable operation, low noise and fuel consumption
- Integrated multiple welding processes: MMA, Cellulose, TIG, Gouging, and FCAW
- Wide current regulating range supporting carbon arc gouging with 8mm or larger carbon rods
- Optional single/double operation models with non-interfering dual welding capability
- Welding current/voltage parameter preset function for easy regulation
Technical Specifications
Dual Welding Output (A & B)
| Parameter | Handle A | Handle B |
|---|---|---|
| Welding Processes | Stick | TIG | Stick | TIG | FCAW |
| No-load Voltage | 76V | 76V |
| Current Range | (30-350A)x2 | 14-50V |
| Welding Current | 350A/300A | 350A/300A |
| Welding Voltage | 34V/32V | 24V/22V | 31.5V/29V |
| Duty Cycle | 60%/100% | 60%/100% |
| External Characteristic | Drop | Flat |
Single Welding Output (A or B)
| Parameter | Handle A | Handle B |
|---|---|---|
| Welding Processes | Stick | TIG | Stick | TIG | FCAW |
| No-load Voltage | 76V | 76V |
| Current Range | 30-350A | 30-600A | 14-50V |
| Welding Current | 300A/350A | 400A/500A | 400A/500A |
| Welding Voltage | 32V/34V | 22V/24V | 34V/39V |
| Duty Cycle | 100%/60% | 100%/60% |
| External Characteristic | Drop | Flat |
Generator Output
| Parameter | Specification |
|---|---|
| Rated Power | 30kW (Max. 33kW) |
| Excitation Type | AVR Brushless Excitation |
| Frequency | 50Hz/60Hz |
| Phase | Tri-phase | Single Phase |
| Output Voltage/Power | AC400V/25kW | AC230V/6.9kW | AC400V/22kW | AC230V/6.9kW |
Engine Options
| Model | Fuel | Rated Power | Rated Speed | Emission Standard |
|---|---|---|---|---|
| Yuchai 4D24TG | Diesel | Prime 36kW (Standby 39.6kW) | 1500r/min | EU STAGE Ⅲ |
| Kubota V3300-T | Diesel | Prime 32.1kW (Standby 35.3kW) | 1500r/min | EU STAGE Ⅲ |
| Weichai WP2.3D40 | Diesel | Prime 36kW (Standby 40kW) | 1500r/min | EU STAGE Ⅲ |
Complete Unit Specifications
| Warning Type | Water Temperature / Oil Pressure / Battery Charge |
| Fuel Capacity | 80L |
| Cooling Method | Water-cooled |
| Fuel Consumption | 7.4L/hr |
| Weight | 850kg |
| Dimensions | 1600(L) * 820(W) * 1050(H) mm |
| Protection Class | IP23 |
Product Images
