WPI-130 Portable Gasoline Welder Generator 130A With AC 0.8Kw / 240V Output Power
Product Details:
Place of Origin: | Chongqing,China |
Brand Name: | GENWELD |
Certification: | CE |
Model Number: | WPI-130 |
Payment & Shipping Terms:
Minimum Order Quantity: | one 20GP |
---|---|
Packaging Details: | Carton |
Delivery Time: | one month |
Supply Ability: | 1000 sets one month |
Detail Information |
|||
Welding Current Range: | D40-130A | Rated Duty Cycle: | 50%/120A/24.8V |
---|---|---|---|
Electrode Size: | 1.6-3.2mm | Rated Auxiliary Output: | Petrol Welder Generator |
Engine Max Power: | 5.2K2/3600rpm | Displacement: | 223CC |
Start Method: | Recoil/Electric | Net Weight: | 40Kg |
Outline Size: | 610*470*480mm | ||
High Light: | portable generator for welding machine,portable gasoline generators |
Product Description
GENWELD WPI-130 130A Petrol Engine Driven Welder/Permanent Magnet Generator With AC 0.8Kw /240V Output Power
Product features:
1. Owns power generating & welding functions;
2. Max.welding current 120A, can weld ¢1.6-3.2mm electrode, output power:AC0.8/240V1.
3. Medieum frequency permanent magnet generator, 90% generating efficiency,
4. Adopts digital inverter control technology, excellent welding performance,
5. Small size, light weight,easy move
GENWELD WPI-130 130A Petrol Engine Driven Welder/Generator Specification:
WELDING | Model | WPI-130 |
Duty cycle | ||
Open circuit voltage(V) | 50 | |
Welding voltage(V) | 21.6-25.2 | |
Current range(A) | 40-130 | |
Duty cycle | 50%120A/24.8V | |
Auxiliary power output | AC 0.8Kw/240V | |
ENGINE | Engine model | AP170F |
Max.power/Speed | 5.2Kw/3600rpm | |
Displacement(CC) | 223 | |
Fuel capacity(L) | 15 | |
Start method | Recoil/Electric | |
WHOLE SET | Net weight(Kg) | 40 |
Outline dimension(mm) | 610*470*480 | |
Protection/Insulation class | IP23 |
