Industrial Rated 250A Engine Driven Welder With AC 7.5kW Auxiliary Output Power
Product Details:
| Place of Origin: | Chongqing, China |
| Brand Name: | GENWELD |
| Certification: | CE |
| Model Number: | LWG250 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 sets |
|---|---|
| Price: | USD2000/Set EXW Factory |
| Packaging Details: | Carton dimension: 790×610×660mm |
| Delivery Time: | 50-60 work days after recived 40% prepayment |
| Payment Terms: | T/T |
| Supply Ability: | 100sets per month |
|
Detail Information |
|||
| Welding Process: | MMA,Cellulose, TIG | Outline Size: | 600*560*600mm |
|---|---|---|---|
| Electrode Size: | MMA:1.6-6.0mm, TIG:1.6-3.2mm | Duty Cycle: | MMA:250A/30V/60%; TIG:250A/20V/60% |
| Auxiliary Output Power: | 120V/240V/60Hz/7.2kW(Rated), 7.5kW(Max); 230V/50Hz/7.2kW(Rated),7.5kW(Max) | Fuel Capacity: | Gasoline 32 Litres |
| Net/Gross Weight: | 114KG | Insulation Grade: | F |
Product Description
Product Description:
Introducing our industrial Engine-driven Arc Welder--LWG250, a powerhouse in the welding industry designed to meet your welding needs with precision and efficiency. This robust welder boasts a Fuel Capacity of 32 litres, ensuring extended operation without the need for frequent refueling, ideal for long welding sessions or demanding projects.
LWG-250 Engine-driven Arc Welder is mainly applied in wild welding without power grid and mulicipal water/gas pipeline emergency repairs, which features in compact structure, walking wheels, easy to move in site.
Specializing in the Arc Welding process, LWG-250 Arc Welder owns reliable and consistent welding performance, producing strong and durable welds with ease. Whether you are a seasoned welder or a beginner looking to hone your skills, LWG-250 Arc welder offers the versatility and power to handle a wide range of welding tasks.
LWG-250 Arc welder can withstand the rigors of welding environments,which is a reliable companion for professional welders and amateurs. Whether you are working on shipping building, oil/gas pipeline construction, steel structure projects, LWG-250 Arc welder will exceed your expectations and deliver exceptional results every time.
Features:
- Industrial multi-processes arc welder(MMA,Cellulose,TIG);
- Welding Current Range: DC 30A/21.2V~250A/30V(MMA/Cellulose), DC30A/11.2V~250A/20V(TIG)
- Auxiliary Output Power: AC rated7.2kW/120V/240V/60Hz, Max:7.5kW(Max);
- AC rated7.2kW/230V/50Hz, Max:7.5kW
- Large fuel tank, long running time:Welding: 150A/26V@11.8h, Power generating: 5.7kW@6.8h
- Compact structure and easy transport with walking wheels
Technical Parameters:
| Welding process | MMA, Cellulose, TIG |
| Welding current range | DC 30A/21.2V~250A/30V(MMA/Cellulose), DC30A/11.2V~250A/20V(TIG) |
| Electrode/Welding wire size | MMA/Cellulose electrode:1.6-6.0mm, TIG welding wire:1.6-3.2mm |
| Auxiliary Output Power | AC rated7.2kW/120V/240V/60Hz, Max:7.5kW(Max); AC rated7.2kW/230V/50Hz, Max:7.5kW |
| Engine Type | 4-Stroke |
| Fuel Capacity | 32 litres |
| Packing Size | 790x610x660mm |
| Net/Gross weight | 114/150kg |
Applications:
Ships, pressure vessels, steel structures, construction, petrochemicals, spiral pipe industry, machinery manufacturing, construction machinery, locomotives, aerospace, pressure vessels, shipbuilding, automobiles, bridges, electric power, railways, boilers, aluminum alloy industries, etc.
