Diesel 200A MMA TIG Welder Generator

Basic Information
Place of Origin: China
Brand Name: Lianwai
Certification: CE
Model Number: LWG230C
Minimum Order Quantity: 5 SETS
Packaging Details: Carton
Delivery Time: 20 work days
Supply Ability: 300 sets per month
Detail Information
Welding Process: MMA, TIG(scratch Arc) Welding Current: 65-210A
Duty Cycle: 60%/210A/28V Auxiliary Power Output: AC 3kW / 220V / 50Hz
Net Weight: 90kg Dimension: 740x560x650mm
Engine: KD192F Diesel Electrode Diameter: ¢2.5-¢5.0mm
High Light:

Diesel MMA TIG Welding Generator

,

210A MMA TIG Welding Generator

,

AC 3kW Engine Driven Arc Welder


Product Description



LWG230C Rated 210A Diesel Welding Generator



Introduction

LWG230C is an industrial portable diesel welding generator, which can output 230A welding current and 220V/50Hz single-phase 3KVA auxiliary AC power. It is ideal for welding in places without power supply and field construction operations.



Characteristics

1. IF power generation technology,
2. Welding current and thrust current are steplessly adjustable.
3. Low-hydrogen basic electrode has good arc performance
4. Beside MMA welding, it also has TIG function (scratch arc ignition type).





Application

1. Oil/gas/water pipeline welding, steel structure welding
2. Repair of fences and agricultural equipment in pastures and farms,
3. Emergency repair welding & power supply



Main specification sheet

Product Model LWG230C
Welding No-load voltage 65-70
Welding current range 40-210A
Duty cycle 60%/210A/28.4V
Electrode diameter ¢2.5-¢5.0mm
Generating Rated generating output power AC 3kW/220V,50/60Hz
Engine Brand KOPO
Model KD192F
Engine power(kW) 8.6
Max rpm 3600
Starting E-start
Lubricant alarm system Yes
Emission(cc) 499
Fuel capacity(L) 5.5
Lubricant capacity(L) 1.65
Fuel consumption(g/k.h) 280
Whole set Insulation Class H level 180℃
Net weight(kg) 90
Overall Dimensions(L×W×H) 740x560x650mm



Diesel 200A MMA TIG Welder Generator 0

Diesel 200A MMA TIG Welder Generator 1

Diesel 200A MMA TIG Welder Generator 2

Diesel 200A MMA TIG Welder Generator 3
