Mini Portable Rated 165A MMA/ 175A TIG IGBT Inverter Welder
| Brand Name: | GENWELD |
| Model Number: | TIG200A |
| MOQ: | 50 SETS |
| Delivery Time: | 20 work days |
| Payment Terms: | L/C, T/T |
IGBT Inverter Welder
,TIG Inverter Welder
,AC220V MMA Inverter Welder
GENWELD TIG200A Argon ARC welding Machine(TIG)
Features:
• The front panel is equipped with overheat-protection and over-current protection indicators. The current display is used to show the current data accurately. The acceptable input voltage range 130 - 260V.
• Three-layer PCB structure ensures the performance of the welding machine. Especially, the power supply board is more safe and stable.
• Hi-speed running fan with more optimized heat sink channel design, which makes the heat dissipation effect is 30% higher than the same type of inverter welding machine.
• Full bridge Inverter IGBT dual modules, large output voltage.
• Large capacitors are more flexible and support to connect with generator use.
• The whole series of products with hot arc starting, arc force, and anti-sticking functions. Easy to start the arc, low-pressure drop, comfortable operation.
• New dust-proof design, nice appearance, more cost-effective, more portable, and lighter.
Application field
• It’s widely used for many kinds of metal welding, like carbon steel, stainless, iron and etc.
Specification sheet
| Model | TIG200A | |
| Input voltage (V) | AC220V | |
| Rated input current(A) | MMA:34 / TIG:23 | |
| Current range(A) | MMA:20-165A TIG:15-175A | |
| No load voltage(V) | 65 | |
| Duty cycle@40℃ | 60% | 100% |
| Max. output current(A) | MMA:165 TIG:175 | MMA:128 TIG:135 |
| Max.output Voltage(V) | MMA:26.6 TIG:17 | MMA:25.1 TIG:15.4 |
| Max. output power(W) | MMA:4389 TIG:2975 | MMA:3212.8 TIG:2079 |
| Rated output current(A) | MMA:165 TIG:175 | MMA:128 TIG:135 |
| Rated output Voltage(V) | MMA:26.6 TIG:17 | MMA:25.1 TIG:15.4 |
| Welding rod(mm) | Tungsten:φ1.0～3.0 | |
| Electrode(mm) for MMA | 2.5/3.2 | |
| Insulation Class | F | |
| Protection Class | IP23 | |
| Dimension (mm) | 375*150*310 | |
| Net weight (kg) | 6.4 | |
| Packing Dimension(mm) | 450*270*345 | |
| Gross weight(kg) | 9.1 | |
| TIG Gun(m) | QQ-150 | |
| Ground Cable+Clamp(m) | 1.5(copper) | |
| Power cable+Plug(m) | 1.5 | |
-
