Inverter Welding Machine
Created with Pixso. SUA200A 200A Gasoline Welder Generator with 5.5Kw Auxiliary Output and Recoil/Electric Start
Detail Information
Place of Origin:
Chongqing,China
Certification:
CE
Rated Duty Cycle:
Portable Generator For Welding Machine
Rated Power Output:
AC5.0Kw/240V Or 120V
Engine Brand & Type:
Senci/SC420
Max. Power/Speed:
9.2Kw/3600rpm
Fuel:
Gasoline
Start Method:
Recoil/Electric
Net Weight:
51Kg
Packing Sizes:
720*600*640mm
Packaging Details:
Seaworthy carton,610*470*480mm, Sets/20GP
Supply Ability:
1000 sets per month
Highlight:

portable generator for welding machine

,

portable gasoline generators

Product Description
SUA200A 200A Gasoline Welder Generator
Portable petrol welding machine with 5.5kW AC auxiliary output and dual recoil/electric start capability. Rated cycle: 60% at 180A/27.2V.
Key Features
  • 200A welding capacity with 60% duty cycle
  • 5.5kW maximum AC auxiliary power output
  • Dual start system: recoil and electric
  • Portable design with integrated wheels and handlebar
  • 25L fuel tank capacity for extended operation
Technical Specifications
Generator Section
Rated OCV 220V (AC)
Rated Power 5.0kW
Maximum Power 5.5kW
Rated Current 22.7A
Welding Section
Duty Cycle 60%
OCV 75V (DC)
Rectifier MDS
Current Range DC 50-200A
Loaded Voltage DC 22-28V
Rated Current/Voltage 180A / 27.2V
Engine Section
Engine Model SC420
Max Power/Speed 9.2kW / 3600 RPM
Displacement 420cc
Start Method Recoil/Electric
Physical Specifications
Tank Capacity 25L
Protection/Insulation Level IP23
Outline Dimensions 710 × 568 × 625 mm
Net Weight 98kg
Gross Weight 103kg
Standard Accessories
  • Battery - 1 set
  • Walking wheels - 1 set
  • Wheel handlebar - 1 piece
  • Electrode holder - 1 piece
  • Hand shield - 1 piece
  • Welding cable - 6m
