Portable 130A Gasoline Welding Generator
Product Details:
| Place of Origin: | Chongqing,China |
| Brand Name: | GENWELD |
| Certification: | CE |
| Model Number: | WPI-130 |
Payment & Shipping Terms:
| Minimum Order Quantity: | one 20GP |
|---|---|
| Price: | USD220-230 per set |
| Packaging Details: | Carton |
| Delivery Time: | one month |
| Supply Ability: | 1000 sets one month |
|
Detail Information |
|||
| Name: | Engine Driven Welding Machine | Rated Duty Cycle: | 50%/120A/24.8V |
|---|---|---|---|
| Electrode Size: | 1.6-3.2mm | Rated Auxiliary Output: | AC0.8Kw/240V |
| Engine Max Power: | 5.2KW/3600rpm | Net Weight: | 40Kg |
| Outline Size: | 610*470*480mm | ||
| High Light: | portable diesel welder generator,gasoline welding machine |
||
Product Description
GENWELD WPI-130 Portable 130A Petrol Welding Generator
Product features:
1. Owns power generating & welding functions;
2. Max.welding current 120A, can weld ￠1.6-3.2mm electrode, output power:AC0.8/240V1.
3. Medieum frequency permanent magnet generator, 90% generating efficiency,
4. Adopts digital inverter control technology, excellent welding performance,
5. Small size, light weight,easy move
Specification:
| WELDING | Model | WPI-130 |
| Duty cycle | ||
| Open circuit voltage(V) | 50 | |
| Welding voltage(V) | 21.6-25.2 | |
| Current range(A) | 40-130 | |
| Duty cycle | 50%120A/24.8V | |
| Auxiliary power output | AC 0.8Kw/240V | |
| ENGINE | Engine model | AP170F |
| Max.power/Speed | 5.2Kw/3600rpm | |
| Displacement(CC) | 223 | |
| Fuel capacity(L) | 15 | |
| Start method | Recoil/Electric | |
| WHOLE SET | Net weight(Kg) | 40 |
| Outline dimension(mm) | 610*470*480 | |
| Protection/Insulation class | IP23 |
